- Recovery
- Vacuum
- Oil injection
- Charge
- Fully automatic
FUNCTIONS
SPECIFICATIONS
MANUALS
- Hand valves free
- Input power: AC110V±10%~50/60Hz
- Recovery rate: ≥95%
- Compressor output: 1HP(220V); 3/4HP(110V)
- Vacuum pump capacity: 8.0cfm
- Accuracy of gas cylinder load cell: ±30g
- Gas cylinder: 50L, 50Kg Max
- Oil bottle capacity: 400ml
- Max. Pressure: 20bar
- Charge speed: 2Kg/Min(max.)
- Display: 7" Touch Screen
- Refrigerant hose: 5m
- High pressure gauge range: -1~30bar
- Low pressure gauge range: -1~16bar
- Highly integrated pipeline manifold
- Heater band, Condenser and cooling fan included
- Pressurization to speed up used oil discharge
- Automatic service reminding
- Average gas state refrigerant recovery speed: 980g/min
Operation Manual
Customers Also Bought
Frequently Asked Questions
What is the capacity of the built-in refrigerant tank in the Heavy Duty AC machine?
The built-in refrigerant tank is 50kg (or 50 litre) max.
Is this Heavy Duty AC machine equipped for 134a or 1234yf AC refrigerant?
Our Heavy Duty AC machine can be configurated for either 134a or 1234yf refrigerant based on customer preferences before leaving the factory.
How often does your AC machine need to have the filter replaced for maintenance? How is it done?
The filter should be replaced every 600 service cycles or when the refrigerant recovery volume reaches 220 lbs. You can purchase a filter or a maintenance kit, which includes a filter, on our website.
After replacing the filter, reset the machine.
For specific steps on replacing the filter and resetting the machine, please refer to the product description of the filter on our website or check the maintenance page under the service section.
